Power directly from your laptop using USB Type-C, so you can scan, save and share where it's most convenient to you.
ADS1300
ADS1300
Scan up to 30ppm
60ipm, 2-sided colour scan
20 Sheet Automatic Document Feeder (ADF)
Power directly via USB Type-C
Control up to 3 scan activity shortcuts direct from the device
Dedicated plastic ID card slot
Make everyday document scanning simple with the ADS-1300 compact, portable document scanner.
Scan and save your paper documents wherever you are working. Whether its utility bill, business documents or medical forms, once plugged into your laptop, you can scan and securely store data digitally and have instant access whenever you need it.
| Usage type | Desktop, Portable |
|---|---|
| Backup clock | Yes |
| Control panel | LED, Keys |
| USB interface | USB Type-C*, USB 2.0 Host (Rear, up to 128GB) |
|---|
| With carton | W 369 ｘ D 158 ｘ H 200 mm |
|---|---|
| With carton | 1.70 kg |
| Without carton | W 288 X D 101 X H 85 mm input tray closed |
| Weight | 1.37 kg |
| Operating | Up to 11 watts |
|---|---|
| Ready mode | 5 watts |
| Sleep mode | Up to 1.3 watts |
| Off | 0.1 watts |
| Operating humidity | 20 to 80% |
|---|---|
| Operating temperature | 5 to 35 degrees celsius |
| Sound power | 62dB |
| Device | Yes |
|---|---|
| Product safety guide | Yes |
| USB cable | Yes |
| Warranty card | Yes |
| Quick setup guide | Yes |
| Types and sizes | Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Non carbon paper, Receipt, Business Card, Plastic Card |
|---|---|
| Weights | 51.8 - 128 gsm, Paper 0.08 ~ 0.14mm, Plastic card thickness embossed up to 1.24mm or without emboss 0.75-1.02mm |
| ADF media sizes | Paper : width 51 - 215.9mm, height 70 - 355.6mm, Plastic card: width min/max 51-55mm, length min/max 80-90mm, Long Paper 5000mm (300dpi 1-sided single paper) |
| Supported OS | For full list of compatible operating systems visit support.brother.com |
|---|---|
| Software supplied - Mac | Brother iPrint&Scan for Desktop, Kofax Power PDF Standard v3, Remote Setup |
| Software supplied - Windows | Brother iPrint&Scan for Desktop, Kofax PaperPort 14SE with OCR, Kofax Power PDF Standard v5, Remote Setup, Easy Setup |
| 2-Sided scan | Yes |
|---|---|
| A4 Scan Speed | 30 |
| ADF | 20 |
| Scan to | Scan to PC (Image), Workflow, SharePoint(On Premise), Cloud |
| Drivers | TWAIN, WIA, ICA, SANE |
| Greyscale | 256 levels |
| Interpolated scan resolution | 1200 x 1200 dpi |
| Scan resolution from ADF | 600 x 600 |
| Optional accessories | Carrier Sheet CS-A3301, Pick-up Roller PUR-2001C, Separation Pad SP-2001C, Output Tray OT-1001C, Legacy Kit (LK-1001CEU, LK-1001CUK), USB Power Adapter (PA-AD-004EU, PA-AD-004UK) |
|---|
| Warranty | 12 months |
|---|
